103 X 315 X 3000 CNC LATHE MACHINE

View Seller Detail

MSZ-4000

Price On Request

Condition	GOOD & RUNNING
Location	OUT OF INDIA
Make	GILDEMEISTER
Model	NEF 710
speed of machine	25 - 1800 rpm
Type	CNC Lathe
Weight	6400 Kg
Year of Mfg	2008
Chuck size	315 mm
Max length of product	3000 mm
Sedal size	420
Spindle dia	103 mm
Type ( All gear or manual)	ALL TYPE GEAR
Quantity	1

Specifications:

MACHINE IS IN RUNNING AND GOOD CONDITION

Center height=355 mm
Center distance=3000 mm
Diameter max over saddle=420 mm
Diameter max over bed=710 mm
Spindle hole diameter=103 mm
Tailstock nose=100 mm
Tailstock nose travel=225 mm
Spindle speeds=25 - 1800 rpm
Machine weight=6400 Kg

n. 1 four jaws table diameter 610 mm
n. 1 self centering chuck diameter 315 mm
n. 2 closed steadies
chip conveyor
CNC ECS 240
Retrofitted in 2008
