| Ton capacity of machines | 300 |
| Quantity | 5 |
Technical data and workspace dimensions
1. Max. power of press slider with 12,7 mm before the lowest position: 300 T
2. Dimension between table and slider before the lowest position and adjust to up with adapter (without table plate): 1066 mm
3. Slider jump: 406 mm
4. Slider adjustment: 305 mm
5. Dimensions of the table plate length x width x thickness: 2438 x 1524 x 152 mm
6. Slider Surface length x width 2438 x 1524 mm
7. Thickness of the adapter: 101 mm
8. Dimention between stands: 2489 mm
9. Hole in the table length x width: 2006 x 1066 mm
10. Number of jumps per minute: 20 24 l/min
11. Quantity of the pneumatic pillows: 2
12. The force of the pillow as a countermeasure: 50 T / 25 T each
13. The force of the pillow as a ejector: 50 T / 25 T each
14. Jump of pneumatic pillows: 254 mm
15. Max. Permissible load capacity of slider at 6 kg/cm^2 pressure: 11000 kg
16. Pneumatic pillows do not have mechanical adjustment of the tables. The appropriate height of the pins above
the table is obtained by selecting the length of the pins.
17. Operation of the pillows without delay.
18. The press has a device for controlling the air that drives the pneumatic device in the tools. Splitter operation timed as needed.
19. Place the pneumatic hose holder in the tool on the left side of the tool when viewed from the front of the press.
20. The press has a table that extends towards the front of the press. Setting channels should be made in the tools.
21. The press is equipped with a mechanical hand for receiving stampings.
The price given in the advertisement is a unit price per one machine (in USD)
