M75 X 150 Tsugami 2 die cylindrical die thread rolling machine

HP 5 HP
Location Out of India
Make TSUGAMI
Model R15A
Weight 2 ton
Max dia of screw / bolt 75 mm
Max Thread Leangth 150 mm
Quantity 1

Specifications:

machine is in running condition
Maximum Rolling Force - 15 TON (M)
Spindle Diameter - 54mm
Spindle Speeds - (4 Step) 20, 36,58, 82 RPM
Max Thread Pitch - 5mm
Spindle Motor - 3.7 KW (5HP)
Hydraulic Unit Motor - 1.5 KW (2HP)
Approx. Floor Size - 1830mm x 1020mm x 1200mm High
