M6 x 75 Chen Tsai Flat die thread rolling machine

View Seller Detail

MSZ-2826

Price: USD 5,330.00
Country of Mfg Taiwan
Location Out of India
Make Chen Tsai
Model ZR15H
Max dia of screw / bolt 6 mm
Max length of screw / bolt 75 mm
Quantity 1

Specifications:

Diameter: 3-6
Screw Length: 50 mm
Thread Length: 75 mm
Moving Dies Stationary Length: 90/105/25
Main Motor: 5 HP
Max. Output: 220-240 pcs/min
Approx. WT.: 1710 kgs
Machine Size: 1900x1530x2050
With Vibrating Feeder and 90 degree feeding system
