M8 X 55 high speed TK Ware 3 die 3 station Bolt former

View Seller Detail

MSZ-2764

Price: USD 27,570.00

Country of Mfg	Taiwan
Cut of Dia	8 mm
Cut of Length	70 mm
HP	10
Location	Out of india
Make	TK Ware
Max Shank Length	55 mm
Max wire dia	8 mm
Model	BF10B-3S
speed of machine	250 ppm
Quantity	1

Specifications:

Forging Station: 3 Station
Cut-Off DIA. (MAX): 8 MM
Cut-Off Length (MAX): 70 MM
Kick-Out Length (MAX): 55 MM
Punch Kick-Out Length (MAX): 12 MM
Cut-Off Quill (DIA.xLength): 28x46 MM
Main Die (DIA.xLength): 50x65 MM
Center Distance Between Dies: 60 MM
Punch Hole (DIA.xLength): 40x77 MM
RAM Storke: 120 MM
Forging Power (TON): 20 tons
Products: M6
Out Put (MAX): 250 PCS/MINUTE
Main Motor: 10 HP
Lubrication Motor: 1 HP
Cooling Motor: 1/2 HP
Lubricant: 120 L
Coolant: 180 L
Approx. Weight: 6500 kgs
