M16 X 300 National 4 Die 4 station long stroke Bolt former

View Seller Detail

MSZ-2555

Price On Request

Country of Mfg	USA
Cut of Dia	16 mm
Cut of Length	340 mm
HP	60
Location	Out of india
Make	National
Max Shank Length	300 mm
Max wire dia	16 mm
Model	164XL
speed of machine	50 ppm
Type	4D4S
Quantity	1

Specifications:

Forging Stations: 4
Max. diameter of wire: 16 mm
Production Rate: 50 ppm
Maximum Diameter: M16
Length Range: 70 to 300 mm
Maximum Die Kick-out: 300 mm
Maximum Cut-off Length: 340 mm
Dies Diameter: 100 x 310 mm
Punch Diameter: 75 x 181 mm
Cut-off Quill: 63.5 x 109.5 mm
Punch Kick-out Length: 30 mm
Dies Pitch: 114.3 mm
Maximum Socket Head Cap Screw: M16 x 280 mm
Maximum Hex Cap Screw: M16 x 300 mm
Motor: 60 HP
