M6 X 60 HBF-523 HBF-523 2D3B Cold Header Machine

View Seller Detail

MSZ-2020

Price On Request

Country of Mfg	Taiwan
HP	Taiwan
Location	Out of India
Make	Huihong
Model	HBF-523
speed of machine	80-120 ppm
Type	2 Die 3 Blow
Weight	3200 kg
Max cutting length	70 mm
Max length {shank} of product	60 mm
Max wire cutting dia	6 mm
Max wire {shank} dia	6 mm
Quantity	1

Specifications:

Punch out stroke : 12 mm
Die-through stroke : 55
35
Stroke of main sliding table : 92mm
Main motor : 5 hp
Diameter of cutting die : 22mm
Die Diameter : 35*81L
45*84L
Distance between shots : mm
Punch diameter :
26*76L
35*76L
31*76L
Weight :3200kg
Screw minimum and max imum size : 2-5mm
Minimum and maximum length under neck : 2-35mm
Pressing force : 17500kg
