M5 X 70 Huihong HBF-5490 4D4S Bolt Former Machine

View Seller Detail

MSZ-2014

Price On Request

Country of Mfg	Taiwan
HP	10
Location	Out of India
Make	Huihong
Model	HBF-5490
speed of machine	100-200 ppm
Weight	4200 kg
Cut of Dia	5 mm
Cut of Length	80 mm
Max Shank Length	70 mm
Max wire dia	5 mm
Type	4D4S
Quantity	1

Specifications:

Machine is in running condition

Punch out stroke : 10mm
Die-through stroke : 52mm
Stroke of main sliding table : 98 mm
Main motor : 10 hp
Diameter of cutting die : 22mm
Die Diameter : 40*71L
Distance between shots : 53mm
Punch diameter : 34*67L
Weight :4200kg
Screw minimum and maximum size : 2-5mm
Minimum and maximum length under neck : 5-46mm
Pressing force : 22000 kg
