Standard Forming Machine
Features:
1. The connection between the body and the crankshaft and the impact connecting rod adopts high-speed bearing connection , which has large bearing force , long service life and high running speed , suitable for processing ordinary products , standard nut
2. The body is made of ductile iron with added alloy , which has high tensile strength and good wear resistance.
3. The main slider adopts a T -shaped design , which makes the operation of the slider more stable . The side plate of the main slider adopts an adjustable design to ensure the running accuracy under long-term trial.
4. The feeding system adopts a two-stage gear transmission system , which has high transmission efficiency and large transmission torque.
5. The cutting system adopts a guide plate to drive the cutter bar , the guide plate reciprocates , and the cutting force is transmitted linearly , with large force and stability and good dynamic balance.
6. The clamp system can be flipped or translated by 180 degrees. Conducive to the arrangement of the molding process.
7. Equipped with a fault detector and safety protection device , it will automatically stop when the equipment fails , giving the equipment and molds maximum protection
8 , the air disc brake with a brake , reducing the electrical power consumption , inching flexible , easy debugging.
Lengthened Forming Machine
Features:
1. The body and the crankshaft are connected by high-speed bearings, and the crankshaft and the impact connecting rod are connected by high wear-resistant zinc-based alloy tiles, which have large bearing capacity, long service life and low maintenance costs.
2. The length of the machine body is longer and wider, the crankshaft eccentricity is increased, the motor power is increased, the flywheel and other related accessories are increased, which is suitable for processing long products, special-shaped non-standard nuts and metal parts.
3. Compared with traditional models, the seven-mold model has one or two more molding stations, which is more conducive to processing products with higher precision and more complex rows.
4. A male mold ejection system can be installed as needed to meet the needs of special parts production
5. A stop device can be installed according to the product characteristics to improve the feeding accuracy.
6. A stable and reliable mechanical jumping device
can be installed as required. 7. A pneumatic clutch brake car can be installed as required. In order to reduce the impact and starting current, protect electrical appliances and motors.
8. A frequency conversion speed regulation device can be installed according to the molding characteristics of the product, and the speed can be adjusted steplessly within a certain range.
